Description
Autel MaxiSys MS908S Pro
Now with 2 Years Free Online Update
For Heavy Duty Vehicles and Equipment
As a new member of Autel’s MaxiSys family, the MaxiSys CV is built on the powerful MaxiSys 908 platform and provides a comprehensive diagnostic solution for virtually all commercial vehicles as well as machines made in North America, Europe and Asia. Offering advanced features and extreme ease-of-use, MaxiSys CV is the ideal solution for independent repair shops, owner-operators and various sized fleets seeking a single scan tool for all their professional heavy duty needs.
Hardware
- Extraordinarily powerful Cortex-A9 quad-core processor
- 9.7” 1024×768 LED-backlit glossy Multi Touch capacitive display with IPS technology
- Internal reliable and fast 32GB Solid State Drive for better performance
- Built-in 5-megapixel rear camera with autofocus and flashlight
- Dual-band (2.4 GHz & 5.0 GHz) 802.11n Wi-Fi to access your favorite web resources
- Unique shop tough ergonomic design features strong rubber protection and housing;
- Built-in rechargeable lithium-ion battery for up to 8 hours of continuous operation
- USB, audio and auxiliary ports make it easy to connect accessories
- The VCI connects to the main unit wirelessly with up to 230 meters working range
Software
- Open source Android Operating System for fast boot-up and multitasking
- Easy and intuitive navigation makes finding what you need simple and fast
- Extensive vehicle coverage for more than 80 US, Asian and European commercial vehicle makes and machines
- Complete capabilities for codes, live data, actuation tests, adaptations and ECU coding
- Displays live data in text, graph, analog and digital gauge for easy data review and analysis
- Configures display options, sets triggers, records and playbacks results with one touch
- Records and playbacks live data to pinpoint troubles of sensors and components
- Cloud-based Data Manager saves customer and vehicle records, scanner data and technician notes
- Remote technical support for convenient demonstration, training and increased customer satisfaction
- Prints out recorded data anytime and anywhere with Wi-Fi technology
- Automatic Wi-Fi updates available in new software releases
Specifications
Operating System: Android™ 4.0, Ice Cream Sandwich
Processor: Samsung Exynos Quad-Core Processor 1.4GHz
Memory: 2GB RAM & 32GB On-board Memory
Display: 9.7 inch LED capacitive touchscreen with 1024×768 resolution
Connectivity: • Ethernet: RJ45 Ethernet Connection • WiFi (802.11 a/b/g/n) • USB: 2.0 • BT v.2.1 + EDR • SD Card (Support up to 32GB) • HDMI
Camera (rear): Rear-facing, 5.0 Megapixel, AF with Flashlight
Sensors: Gravity Accelerometer, Ambient Light Sensor (ALS)
Audio Input/Output: • Microphone • Dual Speakers • 4-Band 3.5 mm stereo/standard headset jack
Power and Battery: 11000 mAh 3.7 V lithium-polymer battery Charging via 12 V AC/DC power supply
Input Voltage: 12 V (9-24 V)
Power Consumption: 6.5 W
Operating Temp.: -10 to 55°C (14 to 131°F)
Storage Temp.: -20 to 70°C (-4 to 158°F)
Housing: Strong plastic housing with protective rubber boot
Dimensions: 300 mm (11.81”) x 220 mm (8.66”) x 50 mm (1.97”)
Weight: NW: 1.42 kg (3.13 lb.), GW: 8.052 kg (17.75 lb.)
Protocols: SAE J1939; SAE J1708; Manufacturer customized J1939; Manufacturer customized J1708; KWP; VPW; UDS-CAN; CDL
Supported Protocols
SAE J1939, SAEJ1708, Manufacture-defined Protocol J1939, Manufacture-defined J1708, KWP, VPW, UDS-CAN, CDL
Package List
MaxiSys CV Tablet
MaxiFlash Elite
Adapter for Deutsch-9
Adapter for Deutsch-6
Adapter for UNI-4
Adapter Case
JW10(x2)
JW9(x2)
JW8(x2)
JW7(x2)
JW6(x2)
JW5(x2)
JW4(x2)
JW3(x2)
JW2(x2)
JW1(x2)
User Manual
Light Fuse
Quick Reference Guide
Main cable
Carry case
USB Cable
Cigarette Lighter
Compact Disc (CD)
AC/DC External Power Adapter
Clipper Cable
Soft Cloth
Packing List
Mini USB Cable
